Spectrometer Module

Meter-Lab. Inc.'s spectrometer is self-developed and manufactured on our own in Korea, providing highly reliable data through high-resolution, high-speed measurement and precise wavelength calibration. We support a user-friendly software like a spectrum viewer and **various SDKs (C++, C#, LabVIEW)**. Our spectrometers deliver very stable performances even in harsh industrial environments through robust design.

분광모듈

Spectrometer

Model Name Wavelength Range Wavelength Resolution Max. Speed Connector Interface Dimensions Weight Wavelength Uncertainty
s-Nova-525 350 nm - 700 nm 0.171 nm 250 kHz FC/PC, SMA Camera Link W 245 mm x D 130 mm x H 82 mm 2.1 kg
s-Nova-840-60-130CL 810 nm – 870 nm 0.03 nm 130 kHz FC/APC, FC/PC, SMA Camera Link W 225 mm x D 162 mm x H 78 mm 2.3 kg
s-Nova-840-60-250CL 810 nm – 870 nm 0.03 nm 250 kHz FC/APC, FC/PC, SMA Camera Link W 225 mm x D 162 mm x H 78 mm 2.3 kg
s-Nova-840-60-20U 810 nm – 870 nm 0.03 nm 20 kHz FC/APC, FC/PC, SMA USB 3.0 W 225 mm x D 162 mm x H 78 mm 2.3 kg
s-Nova-840-60-80U 810 nm – 870 nm 0.03 nm 80 kHz FC/APC, FC/PC, SMA USB 3.0 W 225 mm x D 162 mm x H 78 mm 2.3 kg
s-Nova-840-60-130U 810 nm – 870 nm 0.03 nm 130 kHz FC/APC, FC/PC, SMA USB 3.0 W 225 mm x D 162 mm x H 78 mm 2.3 kg
s-Nova-850-130CL 750 nm – 950 nm 0.1 nm 130 kHz FC/APC, FC/PC, SMA Camera Link W 130 mm x D 246 mm x H 78 mm 2.2 kg
s-Nova-850-250CL 750 nm – 950 nm 0.1 nm 250 kHz FC/APC, FC/PC, SMA Camera Link W 130 mm x D 246 mm x H 78 mm 2.2 kg
s-Nova-850-20U 750 nm – 950 nm 0.1 nm 20 kHz FC/APC, FC/PC, SMA USB 3.0 W 130 mm x D 246 mm x H 78 mm 2.2 kg
s-Nova-850-80U 750 nm – 950 nm 0.1 nm 80 kHz FC/APC, FC/PC, SMA USB 3.0 W 130 mm x D 246 mm x H 78 mm 2.2 kg
s-Nova-850-130U 750 nm – 950 nm 0.1 nm 130 kHz FC/APC, FC/PC, SMA USB 3.0 W 130 mm x D 246 mm x H 78 mm 2.2 kg
s-Nova-1310 1235 nm – 1385 nm 0.15 nm 40 kHz FC/APC, FC/PC, SMA Gigabit Ethernet (RJ45) W 136 mm x D 253 mm x H 68 mm 2kg
s-Nova-1550-60 1520 nm – 1580 nm 0.06 nm 40 kHz FC/APC, FC/PC, SMA Gigabit Ethernet (RJ45) W 245 mm x D 130 mm x H 82 mm 2.6 kg
s-Nova-1550 1490 nm – 1610 nm 0.1 nm 40 kHz FC/APC, FC/PC, SMA Gigabit Ethernet (RJ45) W 142 mm x D 245 mm x H 76 mm 2.7kg

Hyperspectrometer

Model Name Wavelength Range Wavelength Resolution Max. Speed Interface Dimensions Weight Wavelength Uncertainty
s-Nova-530H 514.5 nm - 539.5 nm 0.02 nm 200 kHz USB 3.0 W 410 mm x D 130 mm x H 85 mm 3.4kg
s-Nova-575H 400 nm - 750 nm 0.25 nm 200 kHz USB 3.0 W 225 mm x D 115 mm x H 85 mm 1.6kg
s-Nova-850H 750 nm - 950 nm 0.27 nm 200 kHz USB 3.0 W 140 mm x D 182 mm x H 83 mm 1.8kg
